6-Stall Mare Motel, 12x24 Stalls, 4-Rail
No reviews yet.Write a review
$14,334.52
Size & layout
Stall count, dimensions and row style.
Roof coverage
Stall coverage and breezeway roof.
Walls & rails
Panel style and optional PBR wall siding.
Color & quantity
Steel finish and number of complete kits.
Number of kits
- Estimated delivery in 8 weeks
- Made in the USA
This 6-stall mare motel sets three 12x24 ft stalls on each side of a covered 12 ft breezeway, the plan of a center aisle horse barn with open rail walls. It suits a family herd of grown horses that wants a spare stall for a visiting horse, a newcomer or one kept in for a few days.
Our shop welds the panels, the gate combos and the roof frames. The kit includes the breezeway trusses, purlins, roof sheets and ridge caps, plus the ground posts and the panel clamps and bolts.
- Put it up yourselfAssembly guide
- Or have it installedRequest an installation quote
About 60 x 36 ft, with sun or shade in every stall
The stalls and breezeway take about 60 x 36 ft of ground. Each of these steel horse stalls has a 12 x 12 ft roofed front and an open run of the same size behind, so a horse picks sun or shade. Feeding is three stalls down one side of the aisle and three back up the other.
A level pad and concrete for the posts
Grade a level pad that drains, with room around it for gate swings and a tractor. The kit's ground posts set in concrete you supply, kept off the panel legs, and nothing is welded on site. Ask us for an installation quote if you'd rather hand the job off.
Six stalls of parts to unload
Ask us the length of the longest pieces, then unload on firm, level ground near the pad, after clearing a way for the truck and trailer to come in, turn and leave. A tractor with forks or a skid steer saves a lot of lifting; check the load before the driver goes.
The kit
- Stalls
- 6
- Individual stall size
- 12 x 24 ft
- Rails
- 4 rail
- Steel
- 14 gauge
- Breezeway roof
- Raised center roof
- Siding
- No PBR siding
- Layout
- Two rows of stalls facing the breezeway
- Breezeway
- 12 ft wide
- Roof coverage
- Breezeway and the front 12 ft of each stall; open rear runs
- Panel height
- 5 ft
- Longest piece
- 12 ft
- SKU
- BT-000221
Parts
12 ft x 5 ft 4-Rail Horse Corral Panel
- Length
- 12 ft
- Height
- 5 ft
- Rails
- 4
- Post
- 1-5/8 in
- Rail tubing
- 1-1/4 in
- Center support
- 1-5/8 in
- Rail spacing
- 14-1/4 in
- Steel
- 14 gauge
- Construction
- Welded end caps
Panel Gate Combo 12 ft 4-Rail
- Length
- 12 ft
- Rails
- 4 rail
- Steel
- 14 gauge
12 ft Galvanized Z-Purlin, 6 in Profile
- Profile
- 6 in
- Length
- 12 ft
- Steel
- 14 gauge
- Material
- Galvanized steel
12 x 3 ft Galvalume PBR Roofing Panel
- Size
- 12 x 3 ft
- Steel
- 26 gauge
- Material
- Galvalume PBR
What’s included
Quantities for one kit.
Panels and gates
- 1412 ft 4-rail panels
- 812 ft 4-rail sloped shade assemblies
- 612 ft 4-rail gate combos
Roof
- 3012 ft Z-purlins
- 2712 ft PBR roof sheets
- 276.5 ft PBR roof sheets
- 412 ft center breezeway trusses
- 410 ft ridge caps
Hardware
- 88Panel clamps and bolts
- Ground posts and roofing screws, included with the assemblies
Questions
How does it compare with the 6-stall 5-rail kit?
The layout, stall size and roof are the same. The 5-rail kit, $15,234.51, adds a rail to every panel, shade assembly and gate combo, closing the gaps to 10-1/4 in for foals, ponies and minis; this 4-rail kit is $14,334.52.
Can the six stalls go in one row?
Yes. The 6-stall shed row puts every stall in a single line for a long, narrow site, for $19,555.52. This classic kit needs room for two rows facing across the aisle.
Can I start with six and add stalls later?
Order the count you expect to need, and ask us first if you may want to grow. The same classic kit is $18,639.40 with 8 stalls, and the Number of stalls option also offers 4, 10 and 12.
Can I roof the whole stall?
Yes. The 6-stall fully covered kit, $19,482.84, roofs every stall end to end, so there's no open run. You can also pick Fully covered under Stall roof coverage on this page.
Do I need a permit?
That's up to your county, so ask before you order. Our mare motels aren't engineered structures and aren't built to a building code.
Can I cancel or return it?
No. All sales are final, and orders can't be cancelled once placed. Measure the site and settle the stall count first.
