Arena Swing Gate 4 ft x 12 ft 5-Rail
$425.00each, plus shipping
- Estimated delivery in 1-2 weeks
- Made in the USA
Questions about fit or quantity? Call (619) 914-6657
A 12 ft wide, 4 ft tall arena swing gate with five rails and welded 14-gauge steel construction. Its wider leaf suits an entry planned for machinery and arena access.
Check the 12 ft swing area
Measure the required clear opening for the equipment using the arena, then allow room for the gate to swing. The gate leaf dimensions and installed clear opening need to be checked together.
Five rails create a closer barrier than the four-rail gate of the same width and height. Confirm the adjoining posts and mounting arrangement before ordering.
What’s included
Panels and gates
- 12 x 4 ft swing gate, 5 rail
Hardware
- 2-3/8 in hinge post with heavy-duty ball-bearing hinges welded on
- 1-5/8 in latch post
- Drop latch
- Fully adjustable J-bolt
Not included
- Concrete for the posts
- Installation, quoted separately
- Height
- 4 ft
- Width
- 12 ft
- Rails
- 5 rail
- Steel
- 14 gauge
- SKU
- BT-000373
Shipping cost
Freight is priced from the road miles to your address, as one load, with a $200 minimum. You see the amount before you pay. You can also arrange to pick the order up yourself at our shop in Brady, TX.
Delivery day
Someone must be on site during the carrier’s delivery window. Leave a firm surface and room for a trailer to turn around. The driver calls ahead when they can; a missed window can mean a redelivery charge.
Unloading
You unload. Have a tractor with forks, a skid steer, or enough people to hand-unload. The driver won’t take material off the trailer unless that was agreed in writing before the truck left.
When it arrives
Steel travels loose on the trailer, so scuffs and strap marks are common. Inspect the load, note any damage on the delivery receipt, photograph it at the truck and contact us the same day.
Also in ranch & bow gates
Arena Swing Gate 4 ft x 12 ft 4-Rail
From $400.00
Arena Swing Gate 4 ft x 10 ft 5-Rail
From $350.00
Arena Swing Gate 4 ft x 12 ft 5-Rail Wood Insert
